FIRE RESISITANT FLEX AIRDUCT

FIRE RESISITANT FLEX AIRDUCT

NUMBER of DENSITY	WEFT	8 Pcs/cm
	WARP	8 Pcs/cm
WOVEN	%100 POLYESTER (1100 DTEX )
FABRIC TYPE	ALEVYÜRÜMEZ ( FR )
1st LAYER
FABRIC WEIGHT	200 GR / M2
PVC COATING WEIGHT	450 GR / M2
SPECIFIC WEIGHT/m2	650 GR / M2 (+/- 15 gr/m2)
TENSILE STRENGHT	WEFT	2100 N TS 2008 EN ISO 142/1METHOD:1:2000
	WARP	2100 N
TEAR RESISTANCE	WEFT	210 N TS EN ISO 4674-1 METHOD A:2003
	WARP	210 N
2nd LAYER
FABRIC TYPE	1,5mm IZOLATOR
3rd LAYER
FABRIC WEIGHT	200 GR / M2
PVC COATING WEIGHT	350 GR / M2
SPECIFIC WEIGHT/m2	550 GR / M2 (+/- 15 gr/m2)
TENSILE STRENGHT	WEFT	2100 N TS 2008 EN ISO 142/1METHOD:1:2000
	WARP	2100 N
TEAR RESISTANCE	WEFT	210 N TS EN ISO 4674-1 METHOD A:2003
	WARP	210 N
GENERAL SPECS
FLAMMABILITY	ISO 6941 :2003
HEAT RESISTANCE	-30 / 70+ C
COLOR	YELLOW / WHITE
DIAMETER of PRODUCTION	10 CM – 200 CM
PITCH RANGE	5 CM – 20 CM
WIRE DIAMETER	1.2 mm – 5 mm

ANTI STATIC

ANTI STATIC & FIRE RESISITANT FLEX AIRDUCT

NUMBER of DENSITY	WEFT	8 Pcs/cm
	WARP	8 Pcs/cm
WOVEN	%100 POLYESTER (1100 DTEX )
FABRIC TYPE	ALEVYÜRÜMEZ ( FR )
FABRIC SPECIFICATIONS
FABRIC WEIGHT	200 GR / M2
PVC COATING WEIGHT	480 GR / M2
SPECIFIC WEIGHT/m2	650 GR / M2 (+/- 15 gr/m2)
TENSILE STRENGHT	WEFT	2100 N TS 2008 EN ISO 142/1METHOD:1:2000
	WARP	2100 N
TEAR RESISTANCE	WEFT	210 N TS EN ISO 4674-1 METHOD A:2003
	WARP	210 N
GENERAL SPECS
FLAMMABILITY	ISO 6941 :2003
HEAT RESISTANCE	-30 / 70+ C
COLOR	BLACK
DIAMETER of PRODUCTION	8 CM – 150 CM
PITCH RANGE	5 CM – 20 CM
WIRE DIAMETER	1.2 mm – 5 mm

SEMICIRCLE TENTS

SEMICIRCLE TENTS
SIZE		TARPAULIN		CONSTRUCTION	ISOLATION
WIDTH	HEIGHT	WEIGHT	TYPE	IRON DIAMETER	FELT BIZOFOL METALIZED FOIL ALUMINIUM FOIL IZOCAM FIRE PROOF MAT FLAME PROOF MAT
3,5 4 5 6 7	4 6 8 10 12 14 16 18	435 500 520 540 550 600 620 630 650 680	NORMAL FLAME-PROOF ANTI-BACTERIAL	32 36 38 40 42 48 50

DISASTER RELIEF/FAMİLY TENTS

DISASTER RELIEF/FAMİLY TENTS
SIZE	TARPAULIN				CONSTRUCTION	ISOLATION
AREA	PVC		FABRIC		IRON DIAMETER	FELT BIZOFOL METALIZED FOIL ALUMINUM FOIL MAT IZOCAM FIRE PROOF MAT FLAME PROOF MAT
16 20 24	WEIGHT	HEIGHT	WEIGHT	TYPE	32 36 38 40 42 48 50
16 20 24	435 500 520 540 550 600 620 630 650 680	NORMAL FLAME PROOF ANTI BACTERIAL	130 230 480 520 580 630	COTTON FUNGUS PROOF WATER ANTI BACTERIAL BLACKOUT	32 36 38 40 42 48 50

AIR CHANNEL TENTS

AIR CHANNEL TENTS
SIZE	AWNING				FABRIC
AREA	PVC		FABRIC		WEIGHT	NORMAL FLAME PROOF ANTI BACTERIAL
16 20 24 30 36 40 56 60 72	WEIGHT	TYPE	WEIGHT	TYPE	900 1050 1200
	435 500 520 550	NORMAL FLAME PROOF ANTI BACTERIAL	650	PROOF WATER ANTI BACTERIAL

SCISSOR (STEEL CONSTRUCTION) TENTS

SCISSOR (STEEL CONSTRUCTION) TENTS
SIZE		TARPAULIN		CONSTRUCTION	ISOLATION
WIDTH	HEIGHT	WEIGHT	TYPE	IRON DIAMETER	KEÇE BİZOFOL METALİZE FOLYO ALÜMİNYUM FOLYO İZOCAM YANMAZ MAT ALEV YÜRÜMEZ MAT
8 10 12 14 16 18 20 30	3 6 9 12 15 18 21 24 27 30	680 850 900 1050 1200 1450	NORMAL ALEV YÜRÜMEZ ANTİ BAKTERİYEL	ÇADIR ÖLÇEĞİNE GÖRE STATİK HESAP YAPILARAK ÖZEL TASARLANMAKTADIR

FEATURE	TYPE	Normal	FLAME PROOF	FLAME PROOF + RIPStop	FLAME PROOF + Antistatik	FLAME PROOF + Antistatik+ RIPStop
Φ 20cm. – 280cm. Custom-made Fantube in its range	TWIN CHANNEL / SPIRALLY / FLEXIBLE	x
Φ 20cm. – 280cm. Custom-made Fantube in its range	TWIN CHANNEL / SPIRALLY / FLEXIBLE		x	x
Φ 20cm. – 280cm. Custom-made Fantube in its range	TWIN CHANNEL / SPIRALLY / FLEXIBLE				x
Φ 20cm. – 280cm. Custom-made Fantube in its range	TWIN CHANNEL / SPIRALLY / FLEXIBLE					x
Production size specific to customer demand	TWIN CHANNEL / SPIRALLY / FLEXIBLE	x	x	x	x	x

Our company is engaged in the production fantup make the world’s manufacturing custom manufacturing fantüp to many countries, especially Turkey on fantup.
